상품상세정보

   ???? Low noise analog signal path

   ???? 98 mΩ internal conductor resistance

   ???? Output voltage proportional to AC and DC current

   ???? Min. sensing current 0～1.0A at 5V voltage supply

   ???? High Sensitivity 2mV/mA

   ???? Wide operating voltage range 3.0~12 V.

   ???? Low operating current 3mA

   ???? Nearly zero magnetic hysteresis.

   ???? Ratiometric output from supply voltage

   ???? 10K Hz bandwidth

​​
