   ⊙ Operates from 2.4V to 26V supply voltage
   ⊙ Operation with North or South Pole
   ⊙ On-chip Hall Sensor and driver
   ⊙ On-chip temperature compensation circuitry minimizes shifts in On/Off points

      temperature and supply voltage
   ⊙ On-chip voltage regulator to stabilize On/Off switch point
   ⊙ Wide range operating temperature –20 ~ 85℃
   ⊙ Easily Manufacturability with magnet pole independence

      South or North magnetic field: Output Low

      No magnetic field : Output High.

​​
